Aluminum T-Slot

PROFILES

The T-slot Concept: Built-in Modularity

T-slot aluminum proles offer several benets. The shape of the prole creates modularity, meaning it is easily assembled and reassembled to conform to evolving needs. The T-slot also provides the ability to add connections and join proles to captivated (closed) ends. This allows you to change your design without having to start from scratch and also enables easy expansion and retraction of your build for modications down the road. The T-slot prole concept is designed to allow movement while staying secure within the T-slot.

80/20's Unique 2 Drop-Lock

Another important attribute of T-slot aluminum proles is the strong connection made between proles. 80/20's T-slot aluminum proles include a 2 degree drop-lock feature for most proles, which enables connections to remain vibration resistant and strong. 80/20 offers a wide variety of joining options to t your specic needs (for an overview on fastening products ip to page 18).

Introduction to Aluminum Framing

You have a project or design in mind and now you need to turn that idea into an actual build. Your rst step is to choose your prole; T-slot aluminum proles, Ready Tube, or Quick Frame. If you would like to head directly to information on Ready Tube, ip to page 14, or to page 16 to read about Quick Frame. Let's begin with the T-slot prole.

Connections can be made anywhere along the axis of the prole, creating an innite number of mounting points and eliminating incremental positioning.

2 Drop Lock

ENGAGED NOT ENGAGED
